工作原理 DESCRIPTION |
技术参数 Specifications |
|
当1口压力超过开启压力，油液由1口流向2口，反方向2口到1口关闭。
Pressure at 1 over the cracking pressure allows free flow from 1to 2.Flow in the opposite direction from 2 to 1 is blocked.
|
1.额定压力(Rated pressure)：250bar
2.额定流量(Rated flow):15L/min
3.开启压力(Cracking pressure):9-10bar
4.泄漏量(Internal leakage):2drops/min
5.油液清洁度(Cleaning code):20/18/15(NAS9)
6.工作温度(Temperature range):-20~+100℃
7.安装扭矩(Installation torque):40~45Nm
|
 |
 |
| 机能符号 SYMBOL | 剖视图 CROSS SECTION |
 |
 |
| 插孔 CAVITY | 压力流量曲线 Performance Details |
