工作原理 DESCRIPTION |
剖视图 CROSS SECTION |
|
当①口压力超过开启压力，油液由①流向②,反方向②到①关闭。 Pressure at 1over the cracking pressureallows free flow from 1to 2.Flow in the opposite direction from 2to 1 is blocked.
|
|
|
技术参数
Specifications |
1.额定压力(Rated pressure):315bar
2.额定流量(Rated flow):150L/min
3.开启压力(Cracking pressure):2.5bar
4.泄漏量(Internal leakage):2 drops/min
5.油液清洁度(Cleaning code):20/18/15(NAS9)
6.工作温度(Temperature range):-20~+100℃
7.安装扭矩(Installation torque):38~43Nm
|
|
 |
| 机能符号 SYMBOL | 压力流量曲线 PERFOPMANCE DETAILS |
