EMYF06-17 溢流阀 Relief valves
技术参数 Specifications更多 +
1.额定压力(Rated pressure):200bar
2.额定流量(Rated flow):40L/min
3.开启率(Cracking Rate)≥87%
4.闭合率(Closing Rate)≥82%
5.内泄漏 (Internal leakage) ≤10ml/min at 150bar
6.油液清洁度(Cleaning code):20/18/15(NAS9)
7.工作温度(Temperature range):-20~+100℃
8.每转压力变化(Pressure change per turn):56.5bar
9.安装扭矩(Installation Torque):35~40Nm
10.锁紧扭矩(Nut Tightening Torque):30~34Nm
-
EMYF06B-02 溢流阀 Relief valves
技术参数 Specifications更多 +
1.额定压力(Rated pressure):160bar
2.额定流量(Rated flow):30L/min
3.开启率(Cracking Rate)≥90%
4.闭合率(Closing Rate)≥85%
5.补油开启压力(Oil Makeup Cracking Pressure):1.6bar
6.内泄漏 (internal Leakage)≤10ml/min at 165bar
7.油液清洁度(Cleaning Code):20/18/15(NAS9)
8.工作温度(Temperature range):-20~+100℃
9.每转压力变化(Pressure change Per Turn):76bar
10.安装扭矩(Installation Torque):35~40Nm
11.锁紧扭矩(Nut Tightening Torque):23~28Nm
-
EMYF08-15 溢流阀 Relief valves
技术参数 Specifications更多 +
1.额定压力(Rated pressure):195bar
2.额定流量(Rated flow):80L/min
3.开启率(Cracking Rate)≥90%
4.闭合率(Closing Rate)≥86%
5.内泄漏 (Infernal leakage) ≤10ml/min at 146bar
6.油液清洁度(Cleaning code):20/18/15(NAS9)
7.工作温度(Temperature range):-20~+100℃
8.每转压力变化(Pressure change per turn):54bar
9.安装扭矩(Installation Torque):45~50Nm
10.锁紧扭矩(Nut Tightening Torque):38~43Nm
-
EMYF05-15D 溢流阀Relief valves
技术参数 Specifications更多 +
1.额定压力(Rated pressure):50bar
2.额定流量(Rated flow):20L/min
3.开启率(Cracking Rate)>88%
4.闭合率(Closing Rate)>80%
5.内泄漏 (Internal leakage) <10ml/min at 37bar
6.油液清洁度(Cleaning code):20/18/15(NAS9)
7.工作温度(Temperature range):-20~+100℃
8.每转压力变化(Pressure change per turn):39ban
9.安装扭矩(Installation Torque):35~40Nm
10.锁紧扭矩(Nut Tightening Torque):30~34Nm
-
EMYF05-20 溢流阀 Relief valves
技术参数 Specifications更多 +
1.额定压力(Rated pressure):100bar
2.额定流量(Rated flow):25L/min
3.开启率(Cracking Rate)>85%
4.闭合率(Closing Rate)>80%
5.内泄漏 (Internal leakage) <10ml/min at 75bar
6.油液清洁度(Cleaning code):20/18/15(NAS9)
7.工作温度(Temperature range):-20~+100℃
8.每转压力变化(Pressure change per urn):31bar
9.安装扭矩(Installation Torque):40~45Nm
10.锁紧扭矩(Nut Tightening Torque):38~43Nm
-
EMYF05B-05-300 溢流阀 Relief valves
技术参数 Specifications更多 +
1.额定压力(Rated pressure):300bar
2.额定流量(Rated flow):40L/min
3.开启率(Cracking Rate)>90%
4.闭合率(Closing Rate)>86%
5.补油开启压力(Oil replenishment Cracking Pressure):0.4bar
6.内泄漏(Internal Leakage) <5ml/min at 225bar
7.油液清洁度(Cleaning Code):20/18/15(NAS9)
8.工作温度(Temperature range):-20~+100℃
9.安装扭矩(Installation Torque):40~45Nm
-
EMYF05-12 溢流阀 Relief valves
技术参数 Specifications更多 +
1.额定压力(Rated pressure):70bar
2.额定流量(Rated flow):40L/min
3.开启率(Cracking Rate)>85%
4.闭合率(Closing Rate)>80%
5.内泄漏 (Internal leakage) <10ml/min at 52bar
6.油液清洁度(Cleaning code):20/18/15(NAS9)
7.工作温度(Temperature range):-20~+100℃
8.每转压力变化(Pressure change per turn):22.8bar
9.安装扭矩(Installation torque):38~43Nm
10.锁紧扭矩(Nut Tightening Torque):23~28Nm
-
EMYF04-01 溢流阀 Relief valves
技术参数 Specifications更多 +
1.额定压力(Rated pressure):265bar
2.额定流量(Rated flow):40L/min
3.开启率(Cracking Rate)>83%
4.闭合率(Closing Rate)>79%
5.内泄漏(Internal leakage) <10ml/min at 198bar
6.油液清洁度(Cleaning code):20/18/15(NAS9)
7.工作温度(Temperature range):-20~+100℃
8.每转压力变化(Pressure change per turn):56bar
9.安装扭矩(Installation torque):35~40Nm
10.锁紧扭矩(Nut Tightening Torque):30~35Nm
-
EMXF19-01 溢流阀 Relief valves
技术参数 Specifications更多 +
1.额定压力(Rated pressure):230bar
2.额定流量(Rated flow):95L/min
3.开启率(Cracking Rate) >91%
4.闭合率(Closing Rate)>85%
5.补油开启压力(Oil replenishment Cracking Pressure):8.5bar
6.内泄漏(Internal Leakage)<10ml/min at 172 bar
7.油液清洁度(Cleaning code):20/18/15(NAS9)
8.工作温度(Temperature range):-20~+100℃
9.每转压力变化(Pressure change per turn):54bar
10.安装扭矩(Installation Torque):50~55Nm
11.锁紧扭矩(Nut Tightening Torque):23~28Nm
-
EMXF18 溢流阀 Relief valves
技术参数 Specifications更多 +
1.额定压力(Rated pressure):305bar
2.额定流量(Rated flow):60L/min
3.开启率(Cracking Rate)>88%
4.闭合率(Closing Rate)>82%
5.油液清洁度(Cleaning code):20/18/15(NAS9)
6.工作温度(Temperature range):-20~+100℃
7.每转压力变化(Pressure change per turn):122.5bar
8.安装扭矩(Installation Torque):50~55Nm
9.锁紧扭矩(Nut Tightening Torque):10~12Nm
-
EMXF16-03 溢流阀 Relief valves
技术参数 Specifications更多 +
1.额定压力(Rated pressure):210bar
2.额定流量(Rated flow):150L/min
3.开启率(Cracking Rate)>88%
4.闭合率(Closing Rate)>83%
5.油液清洁度(Cleaning code):20/18/15(NAS9)
6.工作温度(Temperature range):-20~+100℃
7.每转压力变化(Pressure change per turn):103bar
8.安装扭矩(Installation Torque):55~62Nm
9.锁紧扭矩(Nut Tightening Torque):12~17Nm
-
EMXF16-02D二级溢流阀Two valves relief valves
技术参数 Specifications更多 +
1.额定流量(Rated flow):250L/min
2.一级额定压力(Primary Rated pressure):190bar
3.二级额定压力(Secondary Rated pressure):220 bar
4.开启率(Cracking Rate)>87%
5.闭合率(Closing Rate)>82%
6.油液清洁度(Cleaning code):20/18/15(NAS9)
7.工作温度(Temperature range):-20~+100℃
8.每转压力变化(Pressure change per turn):123 bar
9.安装扭矩(Installation Torque):75~80Nm
10.锁紧扭矩(Nut Tightening Torque):35~40Nm
-
EMXF16-02 溢流阀 Relief valves
技术参数 Specifications更多 +
1.额定压力(Rated pressure):210bar
2.额定流量(Rated flow):200L/min
3.开启率(Cracking Rate):>88%
4.闭合率(Closing Rate) :>81%
5.油液清洁度(Cleaning code):20/18/15(NAS9)
6.工作温度(Temperature range):-20~+100℃
7.每转压力变化(Pressure change per turn):172ban
8.安装扭矩(Installation Torque):75~80Nm
9.锁紧扭矩 (Nut Tightening Torque):18~23Nm
-
EMXF15-05 溢流阀 Relief valves
技术参数 Specifications更多 +
1.额定压力(Rated pressure):80bar
2.频定流量(Rated flow):50L/min
3.开启率(Cracking Rate):>85%
4.闭合率(Closing Rate):>80%
5.油液清洁度(Cleaning code):20/18/15(NAS9)
6.工作温度(Temperature range):-20~+100℃
7.每转压力变化(Pressure change per turn):34.8bar
8.安装扭矩(Installation Torque):40~45Nm
9.锁紧扭矩(Nut Tightening Torque):28~34Nm
-
EMXF15-01 溢流阀 Relief valves
技术参数 Specifications更多 +
1.额定压力(Rated pressure):150bar
2.额定流量(Rated flow):100L/min
3.开启率(Cracking Rate) >90%
4.闭合率(Closing Rate)>85%
5.油液清洁度(Cleaning code):20/18/15(NAS9)
6.工作温度(Temperature range):-20~+100℃
7.每转压力变化(Pressure change per turn):170ban
8.安装扭矩(Installation Torque):40~45Nm
9.锁紧扭矩(Nut Tightening Torque):23~28Nm
-
EMXF12-25 溢流阀 Relief valves
技术参数 Specifications更多 +
1、额定压力(Rafed pressure):200bar
2、额定流量(Rated flow):60L/min
3、开启率(Cracking Rate) ：>90%
4、合率(Closing Rate)：>87.5%
5、油液清洁度(Cleanling code):20/18/15(NAS9)
6、工作温度(Temperature range):-20~+100℃
7、每转压力变化(Pressure change per turn):170bar
8、安装扭矩(lstallation Torque):40~45Nm
9、锁紧扭矩(Nut Tightening Torque):23~28Nm
-
EMXF12-08 溢流阀 Relief valves
技术参数 Specifications更多 +
1、额定力(Rafed pressure):142bar
2、额定流量(Rated flow):60L/min
3、开启率(Cracking Rate) ：>90%
4、合率(Closing Rate)：>84%
5、补油开启压力(Anti-CavCracking Pressure):0.55bar
6、内泄漏(Internal Leakage) <5ml/min at 106.5bar
7、油液清洁度(Cleanling code):20/18/15(NAS9)
8、工作温度(Temperature range):-20~+100℃
9、每转压力变化(Pressure change per turn):56.9bar
10、安装扭矩(lstallation Torque):40~45Nm
11、锁紧扭矩(Nut Tightening Torque):18~32Nm
-
EMNDF18-01 反向单向阀 Reverse check valves
技术参数 Specifications更多 +
1、额定压力(Rated pressure):250bar
2、额定流量(Rated flow):150L/min
3、开启压力(Cracking pressure):0.5bar
4、泄露量(Internal leakage):2drops/min
5、油液清洁度(Cleanling code):20/18/15(NAS9)
6、工作温度(Temperature range):-20~+100℃
7、安装扭矩(Installation torque):60~65Nm
-
EMDF22-02 单向阀 Check valves
技术参数 Specifications更多 +
1、额定压力(Rated pressure):315bar
2、额定流量(Rated flow):300L/min
3、开启压力(Cracking pressure):2.5-3bar
4、泄露量(Internal leakage):2drops/min
5、油液清洁度(Cleanling code):20/18/15(NAS9)
6、工作温度(Temperature range):-20~+100℃
7、安装扭矩(Installation torque):75~80Nm
-
EMDF14-02单向阀 Check valves
技术参数 Specifications更多 +
1、额定压力(Rated pressure):315bar
2、额定流量(Rated flow):120L/min
3、开启压力(Cracking pressure):0.2bar
4、泄露量(Internal leakage):1drops/min
5、油液清洁度(Cleanling code):20/18/15(NAS9)
6、工作温度(Temperature range):-20~+100℃
7、安装扭矩(Installation torque):40~45Nm
